This document was generated on 04/02/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Description:
78373-0001
Active
1.00mm Pitch DDR3 DIMM Socket, 25° Angle, Through Hole, with Beveled Metal Pins,
Black Housing and Latches, 0.76μm Gold (Au) Plating, 2.79mm Solder Tail Length,
1.57mm PCB Thickness, 1.5V Center Voltage Key, 240 Circuits
Documents:
3D Model
Drawing (PDF)
Agency Certification
CSA
Product Specification PS-78373-001 (PDF)
RoHS Certificate of Compliance (PDF)
LR19980
image - Reference only
Series
UL
E29179
EU RoHS
China RoHS
ELV and RoHS
General
Compliant
Product Family
Series
Component Type
Electrical Model
JEDEC Outline
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Entry Angle
Flammability
Function Key
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
Voltage Key
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Memory Module Sockets
78373
Socket
Yes
MO-269
DDR3 DIMM
883906206697
240
240
Black
25
25° Angle
94V-0
None
Yes
Copper Alloy
Gold
Tin
High Temperature Thermoplastic
11.547/g
2.79mm
Yes
Yes
1.57mm
Tray
1.00mm
1.00mm
0.762μm
2.540μm
-55°C to +85°C
Through Hole
1A
30V AC (RMS)/DC
Center
10
SMC & Wave Capable (TH only)
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Not Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
78373Series
Mates With
JEDEC Standard 1.27mm Modules
